ADAPTEC CARDS

Adaptec's PCI-X zero-channel RAID card offers the ideal solution for customers who want an affordable, flexible upgrade path to advanced RAID. The Adaptec SCSI RAID 2020ZCR card provides an affordable, high performance solution to businesses requiring data protection. Its low profile form factor is ideal for workstations and high-density server environments. The Adaptec SCSI RAID 2020ZCR card takes advantage of the system motherboard's existing Ultra U320 SCSI I/O channels by using complimentary logic designed on the motherboard. This innovative approach reduces the cost of the RAID card by eliminating the need for a SCSI I/O chip on the card. The Adaptec 2020ZCR card offers high-speed throughput, scalability, space saving features, and a cost-effective upgrade path to a full-feature PCI-X RAID solution. Manufactured by:ADAPTEC Model/Part #:ASR-2020ZCR U320 SCSI 320 MBps Card

As more high-density servers come online, businesses are increasingly requiring advanced RAID functionality in a small form factor. This is exactly the need addressed by the new Adaptec RAID cards. These controllers provide a number of advanced features for entry-level and mid-range servers, such as optimum capacity use of mixed size drives. The Adaptec 2120S supports a range of operating systems (Windows XP/NT/2000, Linux, NetWare, and Caldera) and RAID configurations (0, 1, 10, 5, 50, and JBOD). The card features a low-profile MD2 form factor, and accommodates an optionally available battery backup module (ABM-300) for 72-hour cache memory protection. For single-channel RAID control in high-density servers and workstations, both conventional and rackmount, the Adaptec 2120S is an excellent choice. Manufactured by:ADAPTEC Model/Part :ASR-2120S Controller Type: Storage controller (RAID) - plug-in card - low profile Interface Type: PCI 64 / 66 MHz Controller Interface Type: Ultra320 SCSI Data Transfer Rate: 320 MBps Buffer Size: 64 MB (installed) / 64 MB (max) Supported Devices: Hard drive, disk array (RAID) Channel Qty: 1 Max Storage Devices Qty: 15 RAID Level: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, JBOD Processor: Intel 80302 66 MHz Interfaces: 1 x storage - Ultra320 SCSI LVD - 68 pin HD D-Sub (HD-68) ( internal ) 1 x storage - Ultra320 SCSI LVD - 68 pin VHDCI (mini-Centronics) ( external ) Compatible Slots: 1 x PCI 64 / 66 MHz - low-profile Depth: 6.6 in Height: 2.5 in

Adaptec PCI SCSI controller card 50 pin internal 25 pin External (AVA2902A) Manufactured by: ADAPTEC Model/Part : AVA-2902A Bus System Interface Type: PCI External Connectors: 25-pin, DB25 Internal Connectors: 50-pin, flat cable

The AVA-2902E gives users a high-performance alternative to the computer's slow parallel port. It allows users to take advantage of faster SCSI versions of non-booting peripherals such scanners and zip drives. With wait times reduced up to 80%, the AVA-2902E gives users an increase in system performance, and, since SCSI is the only connection that allows the attachment of multiple external peripherals, the AVA-2902E allows users to connect more devices to their systems. This PCI to SCSI Host Adapter allows for the connection of 7 SCSI devices (internal and/or external), including hard disks, tape drives, CD-ROM drives, and removable media drives. Number of devices: Up to 7 hard disk drives under DOS Bus System Interface Type: PCI - 32 Bit External Connectors: 25-pin, DB25 Internal Connectors: 50-pin, flat cable Data Transfer Rate: Up to 5 Mbytes/sec (synchronous, on the SCSI bus) System Requirements: Microsoft? Windows 95, Windows 3.1, Windows for Workgroups, Windows NT, and MS-DOS SCSI peripheral
