NETGEAR NETWORKING

NETGEAR's DS100 Series 10/100 Mbps Dual Speed Stackable Hubs connect PCs to share e-mail, Internet access, printers, and files. Their exceptional adaptability enables you to mix and match 10 and 100 Mbps PCs, servers, and peripherals on the same network with ease and without any configuration required. Every hub in the DS100 family offers multiple capabilities in a very compact and affordable unit, particularly designed for small business use. Auto-sensing dual-speed ports individually sense and adjust to run at 10 or 100 Mbps, allowing you to upgrade your network speed effortlessly. Every port automatically operates at the proper speed, while the built-in 10 to 100 Mbps bridge automatically discovers where each user is and filters or forwards traffic accordingly. Network ports with built-in LEDs provide clear and intuitive status for instant feedback on hub connections and of network activity. All devices on the same network - whether connected at 10 Mbps or 100 Mbps - operate at maximum performance. Compact metal case design gives you an uncluttered desktop and enables wall-mount installation. Manufactured by: NETGEAR Model/Part : DS116 Device Type: Hub Enclosure Type: External Networking Ports Qty: 16 x Ethernet 10Base-T, Ethernet 100Base-TX Data Transfer Rate: 100 Mbps Data Link Protocol: Ethernet, Fast Ethernet Connectivity Technology: Wired Status Indicators: Port status, link activity, collision status, port transmission speed, power, receive Features: Uplink, MDI/MDI-X switch Compliant Standards: IEEE 802.3u, IEEE 802.3i Interfaces: 16 x network - Ethernet 10Base-T/100Base-TX - RJ-45 female - 16 Compliant Standards: CE, FCC Class A certified, TUV Power Device: Power adapter - external Power Consumption Operational: 18 Watt Compliant Standards: UL, cUL Width: 11.3 in Depth: 4 in Height: 1.1 in Weight: 2 lbs

NETGEAR's DS500 Series Dual Speed Stackable Hubs connect PCs to share e-mail, Internet access, printers, and files. Their exceptional adaptability enables you to mix and match 10 and 100 Mbps PCs, servers, and peripherals on the same network with ease and without the high cost and complexity of multiple hubs and bridges. Up to 8 of these hubs can be stacked to support 192 users at 10 or 100 Mbps, in any combination. Type Ethernet Hub Autosensing dual-speed ports Expandable from 16 to 192 users Full 10/100 Mbps connectivity Easy plug-and-play installation Vista network ports with built-in LEDs Ports 16 x 10Base-T/100Base-TX (RJ-45) Width 13 in. Depth 7.96 in. Height 1.69 in. Weight 4.85 lb.

The model EA201 10Mbps ISA Network Card gets your PC connected for file, print, and resource sharing. True to the NETGEAR mission, the EA201 makes it possible for any Windows PC to be connected to a network with an economically priced network interface card. Plug-and-Play compliance enables the adapter to be automatically configured.The EA201 network card can be installed in 8-bit (XT-style) or 16-bit (AT-style) expansion slots, providing flexibility and investment protection as users add additional hardware and upgrade their system. Max. Data Transfer Rate: 10 Mbps Cabling Type: Ethernet 10Base-T Operating System: Microsoft Windows 3.x , Microsoft Windows NT , UnixWare

NETGEAR's EN100 Series Ethernet hubs connect your PCs for the important functions you need - file, print, resource, and Internet access sharing, e-mail communications, and multi-user network gaming. Flexible, straightforward and cost-effective, these hubs deliver an extraordinary value for users seeking a highly dependable and easy-to-use connectivity solution. NETGEAR's EN100 Series effectively provides data exchange, resource sharing, and client/server or peer-to-peer applications solutions with simple UTP (unshielded twisted-pair) wiring. The hub links to other networks using thin coaxial cables connected to the BNC port, or by using other cabling with appropriate external AUI transceivers for great backbone support. Push-button uplink port simplifies cascading with other hubs for network expansion using standard UTP cables. Slim, sturdy, metal case design means these hubs fit in almost anywhere without cluttering your workspace. Manufactured by: NETGEAR Model/Part : EN106TP Device Type: Hub Enclosure Type: External Ports Qty: 6 x Ethernet 10Base-T Data Transfer Rate: 10 Mbps Data Link Protocol: Ethernet Connectivity Technology: Wired Status Indicators: Port status, link activity, collision status, power Features: Uplink, MDI/MDI-X switch Compliant Standards: IEEE 802.3i Interfaces: 6 x network - Ethernet 10Base-T - RJ-45 female - 6 Compliant Standards: CE, FCC Class A certified, TUV, VCCI Power Device: Power adapter - external Power Consumption Operational: 7.3 Watt Compliant Standards: UL, cUL Width: 13 in. Depth: 8.0 in. Height: 1.7 in. Weight: 4.6 lb.
