NORTEL NETWORKING

External, -48 V Manufactured by: Nortel Model/Part #: AL1904001 Device Type Power converter - external Input Voltage -48 V Frequency Required DC Hz Output Voltage 48 V

The BayStack 70 Switches provide affordable, reliable, and fast connectivity for growing networks. Perfect for cost-conscious customers who don't need complicated management features, but who demand high-speed performance and scalability to support future needs, BayStack 70 Switches boost the performance of desktops by providing dedicated bandwidth directly to users and high utilization servers. In addition to the enterprise-class quality and reliability that Nortel Networks products are known for, BayStack 70 Switches also includes support for thousands of MAC addresses. Affordable enough for a small business' first network, BayStack 70 Switches are designed to scale with a network as the business grows. Now the BayStack idea of "Think Big, Start Small" is truer than ever Manufactured by: NORTEL Model/Part #: AL2001A06 Device Type Switch - stackable Enclosure Type External RAM 512 KB Ports Qty 8 x Ethernet 10Base-T, Ethernet 100Base-TX Data Transfer Rate 100 Mbps Data Link Protocol Ethernet, Fast Ethernet Connectivity Technology Wired Communication Mode Half-duplex, full-duplex Switching Protocol Ethernet Status Indicators Link activity, port transmission speed, port duplex mode, power, link OK Features Uplink, auto-sensing per device Compliant Standards IEEE 802.3, IEEE 802.3u Interfaces 7 x network node - Ethernet 10Base-T/100Base-TX - RJ-45 female - 7 1 x network node / host - Ethernet 10Base-T/100Base-TX - RJ-45 female - 1 Power Device Power supply - internal Voltage Required AC 110/220 V ? 10% ( 50/60 Hz ) Power Consumption Operational 15 Watt

Designed for affordable, incremental deployment and for protecting the network investment of SMBs and branch offices, the Business Policy Switch 2000 delivers an unparalleled solution to boost network performance and productivity - essential to your business profitability. The Business Policy Switch 2000 protects the network investment of cost-conscious SMB and branch-offices looking to deploy converged voice, video and mission-critical applications in a reliable manner, while simultaneously optimizing existing network resources to reduce their overall IT expenditures. When you implement the Nortel Networks Business Policy Switch 2000 in your network, you can anticipate potential performance issues before they become a problem, utilize bandwidth more efficiently, optimizing your existing network resources and capabilities. Manufactured by: NORTEL Model/Part #: AL2001E15 Device Type Switch - stackable Enclosure Type External Ports Qty 24 x Ethernet 10Base-T, Ethernet 100Base-TX Data Transfer Rate 100 Mbps Data Link Protocol Ethernet, Fast Ethernet Remote Management Protocol SNMP 1, RMON, SNMP 3, HTTP Connectivity Technology Wired Switching Protocol Ethernet MAC Address Table Size 16K entries Status Indicators Port status, link activity, power Features Modular design, network monitoring, IGMP snooping Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.1p Expansion Slots Total (Free) 1 MDA Interfaces 24 x network - Ethernet 10Base-T/100Base-TX - RJ-45 female - 24 1 x management - RS-232 - 9 pin D-Sub (DB-9) female - 1 1 x network host - Ethernet 10Base-T/100Base-TX - RJ-45 female - 1 Rack Mounting Kit Included Authentication Method RADIUS Compliant Standards CE, EN 61000-3-2, EN50081-1, EN 61000-3-3, EN55022 Class A, AS/NZ 3548 Class A, ICES-003 Class A Power Device Power supply - integrated Voltage Required AC 120/230 V ( 50/60 Hz ) Power Consumption Operational 40 Watt

Nortel Networks introduces the next generation of the most successful workgroup switches ever. Completely redesigned for faster throughput, support for high-speed uplink options, and leading-edge software features, BayStack 350 Switches carry on the Nortel Networks tradition of affordable, high-performance workgroup switching. BayStack 350 Switches support 10/100 autosensing on all UTP ports, for seamless migration to 100 Mbps connections without time-consuming trips to the wiring closet whenever end stations are upgraded to Fast Ethernet. To further simplify network setups, all ports also automatically sense half- or full-duplex connections for high-speed server or switch-to-switch configurations. Manufactured by: NORTEL Model/Part #: AL2012A10 Device Type Switch Enclosure Type External Processor X Motorola MC68306 RAM 1 MB Flash Memory 512 KB flash Ports Qty 24 x Ethernet 10Base-T, Ethernet 100Base-TX Data Transfer Rate 100 Mbps Data Link Protocol Ethernet, Fast Ethernet Remote Management Protocol RMON 2, SNMP, RMON Connectivity Technology Wired Switching Protocol Ethernet MAC Address Table Size 8K entries Features Auto-sensing per device, trunking, VLAN support, port mirroring, manageable Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D Expansion Slots Total (Free) 1 ( 1 ) x MDA Interfaces 24 x network - Ethernet 10Base-T/100Base-TX - RJ-45 1 x management - RS-232 - 9 pin D-Sub (DB-9) Compliant Standards CE, FCC Class A certified, TUV, CISPR 22 Class A, EN 60950, IEC950, UL 1950, VCCI-I, CSA 22.2 No. 950, EN55022 Class A Power Device Power supply - internal Voltage Required AC 120/230 V ( 50/60 Hz ) Power Consumption Operational 130 Watt Weight 10.8 lbs
