BayStack 450 Switches are stackable Ethernet switches featuring fail-safe stackability, flexible choices for high-speed uplinks, and advanced software features. BayStack 450 Switches are designed to provide high-density, high-performance switching for enterprise wiring closets, and to provide fail-safe scalability and advanced traffic management for rapidly growing networks in demanding environments. BayStack 450 Switches also include advanced features such as VLAN trunking, priority queuing, and IGMP snooping. BayStack 450 Switches also provide network resilience and advanced management with MultiLink Trunking, LinkSafe redundant uplink ports, RMON on every port, complete integration into Optivity network management software, and Web-based management. Manufactured by: NORTEL Model/Part #: AL2012A15 Device Type Switch - stackable Enclosure Type Rack-mountable - external Installed Modules Qty (Max) 0 (installed) / 2 (max) Ports Qty 12 x Ethernet 10Base-T, Ethernet 100Base-TX Data Transfer Rate 100 Mbps Data Link Protocol Ethernet, Fast Ethernet Remote Management Protocol RMON 1, RMON 2, SNMP Connectivity Technology Wired Communication Mode Full-duplex Switching Protocol Ethernet Status Indicators Port status, link activity, port transmission speed, power Features Auto-sensing per device, manageable Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.1p Expansion Slots Total (Free) 2 ( 2 ) x expansion slot Interfaces 12 x network - Ethernet 10Base-T/100Base-TX - RJ-45 female - 12 1 x management - RS-232 - 9 pin D-Sub (DB-9) male - 1 Power Device Power supply - internal Voltage Required AC 110/220 V ? 10% ( 50/60 Hz ) Power Consumption Operational 120 Watt Compliant Standards EPA Energy Star

The BayStack 420-24T Switch is a stackable 10/100/1000 layer 2 Ethernet switch featuring easy configuration and stackability, flexible choices for high-speed uplinks, and web-based management from a Web browser. Combining high-port density with lower per-port pricing for a cost-effective switching solution, the BayStack 420 is designed for the requirements of small- to medium-sized businesses and branch offices. Each BayStack 420-24T Switch has 24 10BaseT/100BaseTX autosensing ports, one GBIC-based (Gigabit Interface Converter) uplink slot and built-in stacking connectors. It can be used as a standalone switch or in a stack of up to 8 switches (up to 192 ports) that can be easily managed as a single entity. Advanced features such as VLAN support, MultiLink Trunking, Simple Network Management Protocol (SNMP) and Web-based management tools help Network Managers to efficiently control network traffic. Built-in Gigabit stacking connectors provide easy connections to other switches in the stack and save money by not requiring additional cascade modules. The scalable architecture is designed to protect your network investment, as your business grows. BayStack 420-24T Switch offers a built-in GBIC (Gigabit Interface Converter) slot that provides high-speed connection to backbone switches or servers. A variety of GBIC module options gives you flexibility in fiber interfaces to connect to distant servers or a larger network, including SX, LX, XD (50 km) and ZX (70 km) for long haul connectivity. Manufactured by: NORTEL Model/Part #: AL2012A39 Device Type Switch - stackable Enclosure Type External - 1U Installed Modules Qty (Max) 0 (installed) / 1 (max) Ports Qty 24 x Ethernet 10Base-T, Ethernet 100Base-TX Data Transfer Rate 100 Mbps Data Link Protocol Ethernet, Fast Ethernet Remote Management Protocol SNMP, RMON, Telnet, HTTP Connectivity Technology Wired Communication Mode Half-duplex, full-duplex Switching Protocol Ethernet MAC Address Table Size 8K entries Features Full duplex capability, auto-sensing per device, BOOTP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, manageable, stackable Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3x Expansion Slots Total (Free) 1 ( 1 ) x GBIC Interfaces 24 x network node - Ethernet 10Base-T/100Base-TX - RJ-45 1 x network stack device x 2 Power Device Power supply - internal Voltage Required AC 120/230 V ( 50/60 Hz ) Power Consumption Operational 50 Watt

The Nortel Ethernet Switch 470 models are stackable 10/100 Mbps Ethernet Layer 2 switches. The Ethernet Switch 470 includes two built-in GBIC (Gigabit Interface Converter) uplink ports and built-in stacking ports in a compact, 1 rack-unit high design. They are designed to provide high-density desktop connectivity for mid-size and large enterprise customers' wiring closets. The Ethernet Switch 470-48T allows configuration flexibility: Port 47 and Port 48 can be configured as either 10/100BASE-TX or make use of the built-in GBIC. Up to eight Ethernet Switch 470-48T models can be stacked to achieve up to 384 10/100 ports for high-density desktop switching. Manufactured by: NORTEL Model/Part #: AL2012E34 Device Type Switch - stackable Enclosure Type External - 1U Ports Qty 48 x Ethernet 10Base-T, Ethernet 100Base-TX Max Units In A Stack 8 Data Transfer Rate 100 Mbps Data Link Protocol Ethernet, Fast Ethernet Routing Protocol IGMPv2, IGMP Remote Management Protocol RMON 2, SNMP, RMON, Telnet, SNMP 3, HTTP Connectivity Technology Wired Switching Protocol Ethernet MAC Address Table Size 16K entries Status Indicators Port status, port transmission speed, power, system, status Expansion Slots Total (Free) 2 ( 2 ) x GBIC Interfaces 48 x network - Ethernet 10Base-T/100Base-TX - RJ-45 2 x network stack device 1 x management - console - 9 pin D-Sub (DB-9) Cables Included 1 x stacking cable - 1.5 ft Authentication Method Secure Shell (SSH), RADIUS Compliant Standards CE, CISPR 22 Class A, CISPR 24, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, UL 60950, CSA 22.2 No. 60950, CB, AS/NZS 60950-1, FCC Part 15, ICES-003 Class A, AS/NZS 3548, RoHS Power Device Power supply - internal Voltage Required AC 120/230 V ( 50/60 Hz ) Power Consumption Operational 90 Watt
