Description
With millions of small- to medium-sized enterprises existing today, the requirement for carriers to provide integrated voice and data solutions is growing at a rapid rate. ADTRAN delivers with the industry-leading Total Access Integrated Access Devices (IADs). The Total Access 624 is a cost-effective, fixed-port, IAD designed to support either TDM or emerging packet architectures. This IAD offers enterprise users and integrated communications providers, such as CLECs, ILECs, and ISPs, a means to offer combined voice and data traffic over a single network interface terminating at the customer’s premises.
Manufactured by:ADTRAN
Model/Part :4213624L3
Device Type: Router
Enclosure Type:Desktop
Connectivity Technology: Wired
Data Link Protocol: Ethernet, ATM, Fast Ethernet, Frame Relay, PPP, V.35, FRF.5, FRF.8
Network / Transport Protocol: TCP/IP, UDP/IP, AAL2, ICMP/IP, IPSec, PPPoA, AAL5, ARP
Routing Protocol: RIP-1, RIP-2
Remote Management Protocol: SNMP 1, Telnet, HTTP
Authentication Method: RADIUS, PAP, CHAP, Extensible Authentication Protocol (EAP)
Features: DHCP support, NAT support, PAT support, ARP support, Syslog support, packet filtering, manageable, firmware upgradable, Quality of Service (QoS)
Compliant Standards: IEEE 802.3, ANSI T1.403, IEEE 802.1D , FCC Class A certified, ETSI, cUL, EN 60950, UL 1950, EN50082-1, FCC Part 68, FCC Part 15, EN 55022
Built-in: DevicesLED panel
Status Indicators: Port status, link activity, power, transmit, receive
Line Rate: T-1
Line Coding Format: AMI, B8ZS
Framing Format: ANSI T1.403, AT&T 54016, D4, ESF, SF
Type: Voice interface card
Analog Ports Qty: 24
Protocols & Specifications: ITU G.165, ITU G.168
Data Compression Protocol: G.711, G.726
VoIP Functionality: VoIP phone adapter
VoIP Protocols: MGCP
Voice Codecs: G.711, ADPCM, G.726
Telephony Interfaces: 24 phone (FXS)
IP Telephony Features: Echo cancellation (G.168)
Interfaces: 1 x 10Base-T/100Base-TX – RJ-45 Serial : 1 x V.35 – 34 pin M/34 (V.35) Management : 1 x RS-232 – RJ-48C Phone line : 24 x FXS – 50 pin Telco WAN : 1 x T1 – RJ-48C WAN : 1 x DSX-1
Power Device: Internal power supply
Voltage Required: AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 40 Watt
Width: 17 in
Depth: 8.5 in
Height: 1.7 in
