Description
HP JD057A IntelliJack Gigabit switches are compact 10/100/1000 switches that can be installed in a standard wall outlet box, quickly converting an existing single-port LAN wall outlet into four switched Gigabit Ethernet ports. These “network jacks” provide a simple solution for adding network ports without running more cabling. Unlike conventional desktop switches, HP IntelliJack devices reside out of the way-literally in-the-wall-and so are more secure from theft and difficult to accidentally disconnect or damage. The innovative HP IntelliJack switches provide four Ethernet ports for local connectivity plus one uplink port. Two additional RJ-45 “pass-through ports” flexibly support a range of additional service and user connectivity options. It can be powered locally or via Power over Ethernet (PoE), and can output standard PoE on up to two ports to directly power attached devices such as IP phones or wireless access points
Key Features
- Manufactured by:HP
- Model/Part : JD057A
- Standards: IEEE 802.1p (CoS), IEEE 802.1Q (VLANs),IEEE 802.1X (Authentication),IEEE 802.3ab (1000BASE-T),IEEE
- 802.3ad (Link aggregation).IEEE 802.3af and 802.3at (Power over Ethernet)
- IEEE 802.3i (10BASE-T),IEEE 802.3u (Fast Ethernet)
- Network Management Type: Managed
- Primary Ports: 4 x 10/100/1000 BASE-TX ports, RJ-45 connectors, 1 x 10/100/1000BASE-TX port for uplink, 2 x
- RJ-45 pass-through ports for legacy analog and digital connectivity
- Primary Port Speed: 10/100/1000Mbps
- VLAN Support: IEEE 802.1Q VLANs
- Security: Network login with IEEE 802.1X, User authentication, Multiple VLAN configurations
- PoE: IEEE 802.3af PoE forwarding through ports #1 and #2
- SNMP: Compatible with SNMP v1 and v2
- QoS: IEEE 802.1p QoS
- LEDs: Unit power, link activity/status of ports, power forwarding
- Power: PoE 48V DC Input
- Dimensions: 5.10″ x 3.16″ x 1.60″
FAQ
- Q: What is the HP JD057A used for?
A: The HP JD057A is a compact in-wall managed Gigabit Ethernet switch designed for business environments such as offices, conference rooms, hotels, classrooms, and other professional installations where multiple wired network connections are needed from a single wall location. - Q: How many ports does the HP JD057A have?
A: The HP JD057A provides 4 local Gigabit Ethernet ports for device connections. It also includes 1 uplink port and 2 RJ-45 pass-through ports. - Q: Is the HP JD057A a managed switch?
A: Yes, the HP JD057A is a managed Gigabit Ethernet switch designed for business network environments. - Q: Is this a desktop switch?
A: No, the HP JD057A is an IntelliJack in-wall switch designed to fit into a wall installation for a cleaner and more professional networking setup. - Q: Where can the HP JD057A be installed?
A: The HP JD057A is commonly used in offices, hotel rooms, conference areas, classrooms, and other commercial environments where space-saving wired network access is needed. - Q: Is the HP JD057A tested before shipping?
A: Yes, this HP JD057A switch is tested and factory reset before shipment for dependable deployment. - Q: What is included with the HP JD057A?
A: The package includes the HP JD057A switch unit. Mounting bracket is included when available. - Q: Is the mounting bracket always included?
A: Mounting bracket is included when available, but availability may vary depending on stock. - Q: Is this HP JD057A suitable for business use?
A: Yes, the HP JD057A is designed for business and commercial networking applications that require reliable Gigabit Ethernet connectivity in a compact in-wall form factor.
