Description
NETGEAR’s non-blocking FSM726S is a Layer 2 managed switch that’s intuitive enough for new users but powerful enough for experienced professionals. With the utility of 24 10/100 ports, two rear stacking ports, and two Gigabit Ethernet ports ? using either built-in copper or GBIC slots ? small and growing business networks can accommodate as many as 250 users and utilize up to 12 Gigabit Ethernet ports. Built-in stacking ports provide simple, cost-effective stacking ? no optional modules required. The FSM726S stacks up to six units, and comes with the stacking cable. The versatile FSM726S offers two management interface options: an easy-to-use, browser based interface and a command line interface. Easy to buy, set up and use, the FSM726S is a compelling value.
Manufactured by: NETGEAR
Model/Part : FSM726S
Product Type: Switch – stackable
Enclosure Type: Rack-mountable – external
Installed Modules Qty (Max): 0 (installed) / 2 (max)
Networking Ports Qty: 24 x Ethernet 10Base-T, Ethernet 100Base-TX
Auxiliary Network Ports: 2x1000Base-T(uplink)
Data Transfer Rate: 100 Mbps
Data Link Protocol: Ethernet, Fast Ethernet
Remote Management Protocol: RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, HTTP
Connectivity Technology: Wired
Switching Protocol: Ethernet
MAC Address Table Size: 8K entries
Status Indicators: Port status, link activity, collision status, port transmission speed, port duplex mode, power, link OK
Features: Flow control, uplink, layer 2 switching, auto-sensing per device, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), manageable, stackable
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x
Expansion Slots Total (Free): 2 ( 2 ) x GBIC
Interfaces: 24 x network node – Ethernet 10Base-T/100Base-TX – RJ-45 female – 24 1 x management – RS-232 – 9 pin D-Sub (DB-9) – 1 2 x network stack device – 2 2 x network host – Ethernet 1000Base-T – RJ-45 female – 2
Compliant Standards: CE, FCC Class A certified, UL, TUV, VCCI, C-Tick
Power Device: Power supply – integrated
Voltage Required: AC 100/220 V ? 9% ( 50/60 Hz )
Power Consumption Operational: 36 Watt
Compliant Standards: UL, cUL, CSA, UL 1950, EN 60950
Width: 17.3 in
Depth: 8.1 in
Height: 1.7 in
Weight: 7.1 lbs
