Description
NETGEAR delivers wirespeed Gigabit performance and a full set of Layer 2 management features, as well as static routing with unsurpassed affordability. This next-generation, high-speed switch delivers maximum throughput where you need it – to high-performance workgroups at the edge of the network, or as a backbone for Fast Ethernet switches and high-speed servers in demanding small networks. The non-blocking design offers full Gigabit throughput simultaneously to all 48 10/100/1000 ports to ensure reliable performance. Flexible fiber connectivity is enabled through four combination small form-factor pluggable (SFP) Gigabit interfaces. Layer 2 management functionality delivers reliability, control, and availability. Static routing enables inter-VLAN routing and provides a faster network and more effective bandwidth management. Access control lists (L2-L4) provide robust security, while L2-L4 based QoS provides enhanced traffic management capabilities. The cost-effective NETGEAR ProSafe 48-port Gigabit L2 Managed Switch creates a more productive – and future-proof – network.
Manufactured by: NETGEAR
Model/Part : GSM7248R
Product Type: Switch
Enclosure Type: External – 1U
Localization: North America
Memory RAM: 64 MB
Flash Memory: 32 MB flash (firmware)
Networking Ports Qty: 48 x Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Data Transfer Rate: 1 Gbps
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Routing Protocol: Static IP routing
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2
Connectivity Technology: Wired
Communication Mode: Half-duplex, full-duplex
Switching Protocol: Ethernet
MAC Address Table Size: 8K entries
Status Indicators: Link activity, port transmission speed, power, link OK
Features: Flow control, layer 2 switching, auto-sensing per device, DHCP support, auto-negotiation, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, Broadcast Storm Control, firmware upgradable, SNTP support, Access Control List (ACL) support, Quality of Service (QoS)
Compliant Standards: IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1v
Expansion Slots Total (Free): 4 ( 4 ) x SFP (mini-GBIC)
Interfaces: 1 x management – console 48 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45
Encryption Algorithm: TLS 1.0, SSL 3.0
Authentication Method: Secure Shell (SSH), RADIUS, Secure Shell v.2 (SSH2)
Compliant Standards: CE, FCC Class A certified, C-Tick, VCCI Class A ITE, EN55024, EN55022 Class A, FCC Part 15, UL 60950-1, EN 60950-1
Power Device: Power supply – internal
Voltage Required: AC 120/230 V ( 50/60 Hz )
Power Consumption Operational: 71.5 Watt
Width: 17.3 in
Depth: 8.1 in
Height: 1.7 in
Weight: 9.3 lbs
