Description
Now you can enjoy full Layer 3, Gigabit functionality at an affordable price. The NETGEAR Managed Gigabit Switch provides maximum throughput and flexibility for demanding networks, with all the Layer 3 features you expect. This 10/100/1000 switch addresses today’s high-performance requirements, while providing the control you need – and the future proofing you want. The GSM7324 is ideal as a backbone for 10/100 switches, Gigabit servers, or as the robust core of a demanding, all-Gigabit network.
The GSM7324 can be used to inexpensively off-load routers that are segmenting your network and lay the groundwork for new IP-based services. Layer 3 routing combined with Quality of Service, bandwidth provisioning and access control features enable Voice over IP (VoIP) telephony, video conferencing, and other cost-saving applications.
Manufactured by: NETGEAR
Model/Part : GSM7324
Product Type: Switch
Enclosure Type: Rack-mountable – 1U
Installed Modules Qty (Max): 0 (installed) / 4 (max)
Localization: North America
Memory RAM: 128 MB
Flash Memory: 8 MB flash
Networking Ports Qty: 24 x Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Data Transfer Rate: 1 Gbps
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Routing Protocol: RIP-1, RIP-2, IGMPv2, VRRP, OSPFv2
Remote Management Protocol: RMON 1, RMON 2, SNMP, RMON 3, RMON 9, Telnet, HTTP
Connectivity Technology: Wired
Switching Protocol: Ethernet
MAC Address Table Size: 16K entries
Status Indicators: Port status, link activity, port transmission speed, power
Features: Layer 3 switching, layer 2 switching, auto-sensing per device, DHCP support, auto-negotiation, BOOTP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, manageable
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w
Expansion Slots Total (Free): 4 ( 4 ) x SFP (mini-GBIC)
Interfaces: 24 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45 1 x management – RS-232
Compliant Standards: CE, FCC Class A certified, CSA, UL, TUV, C-Tick, cUL, EN 60950, EN50082, EN55022, UL 1950, VCCI Class A ITE, EN55024
Power Device: Power supply
Width: 17.3 in
Depth: 15.2 in
Height: 1.7 in
Weight: 12.1 lbs
